Alupanel X-Lite is the definitive choice for professionals seeking maximized cost-efficiency without compromising on the professional finish of a rigid substrate.
Specifically engineered for short-term projects and high-volume rollouts, X-Lite utilizes thinner aluminium skins to deliver a trusted, lightweight solution.
It represents the perfect strategic balance: the budget-friendly nature of flexible materials combined with the superior, ultra-smooth surface of a premium Aluminium Composite Panel (ACP).
-Engineered as the ultimate high-value choice for large-scale or short-term projects. It allows businesses to achieve professional-grade results while maintaining a lean budget offering a high return on investment for temporary applications.
- The optimized skin thickness significantly reduces the panel's weight, making it exceptionally efficient to transport and handle. This efficiency translates to faster on-site installation and easier cutting for smaller-scale signage.
- Despite its focus on cost-efficiency, X-Lite provides an incredibly flat and uniform finish. This ensures superior ink adhesion for direct digital printing and a flawless, ripple-free base for vinyl applications.
- Designed to be lightweight yet maintain an extremely rigid profile. This built-in stability ensures that the panel retains its shape and professional appearance, far outperforming flexible substrates in short-term rigid displays.
- High UV resistance ensures that the panel remains stable and visually consistent in outdoor environments. This makes it a dependable choice for exterior hoarding and short-term promotional signage that needs to withstand the elements
For further information, you can access the product brochures and technical documents below.
VIEW BROCHURES
Alupanel X-Lite is recommended for temporary, non-load bearing, flat applications.
Here are the sheet sizes and thicknesses available as standard along with the technical specification of Alupanel X.
| Panel Thickness (mm) | 2mm | 3mm |
|---|---|---|
| Skin Thickness (mm) | 0.12mm | 0.12mm |
| Weight (KG/m2) | ||
| 1000mmx2015mm | ||
| 1000mmx2440mm | ||
| 1000mmx2050mm | ||
| 1000mmx3050mm | ||
| 1220mmx2440mm | ||
| 1220mmx3050mm | ||
| 1250mmx2550mm | ||
| 1250mmx3050mm | ||
| 1500mmx3050mm | ||
| 1500mmx4050mm | ||
| 1525mmx3050mm | ||
| 1560mmx3050mm | ||
| 2000mmx3050mm | ||
| 2000mmx4050mm | ||
| 2050mmx3050mm | ||
| 2050mmx4050mm |
| Panel Thickness (mm) | |
|---|---|
| Sound Absorption | 0.05 |
| Sound Attenuation | |
| Water Absorption % by Volume | 0.01 |
| Thermal Performance R Values | |
| Core Composition | 100% Recycled LDPE |
| Fire Performance | EN 13501 C-s2,d0 |
| Tensile Strength of Aluminium Layers | 186 |
| Panel Thickness (mm) | +/- 0.2 |
|---|---|
| Width (mm) | -0 +2 |
| Length (mm) | -0 +3 |
| Diagonal | -0 +5 |
| Thermal Expansion | 2.4mm/m @100˚C Temp Difference |
| Aluminium Thickness | ± 0.02 |
| Paint Thickness (microns) | |
|---|---|
| Pencil Hardness | >HB |
| Toughness of Coating | 3T |
| Temperature Resistance | -50˚C to +80˚C |
| Impact Strength (kg/CM2) | |
| Boiling Water Resistance | Boiling for 2hrs without change |
| Acid Resistance | Immerse Surface in 2% HC1 for 24hrs without change |
| Alkali Resistance | Immersed surface in 2% NaOH for 24hrs without change |
| Oil Resistance | Immerse Surface in 20# engine oil for 24hrs without change |
| Solvent Resistance | Cleaned 100 times with Dimethylbenzene without change |
| Cleaning Resistance | >1000 times without change |
| Peel Strength | >5 Newton / mm |
Alupanel X-Lite is available in Signal White digital matt and white primer to cover all of your every day basic requirements. Available in a double or single-sided panel.
Here you will find a range of supporting documents for our product range which will be updated and added to periodically.
In the meantime, if you require any further information please contact us
